Properties

Stärke in mm: 12 mm

Sylomer-Polyurethanlager SR 450

Product number: 85SR045012
Stärke in mm
lfm

Description

Sylomer impact sound bearing SR 450

Area of application Pressure load

Deformation

Form factor dependent, the specified values apply to form factor q = 3

Static area of application
(static loads)

up to 0,45 N/mm²

approx. 10 %

Dynamic area of application
(static and dynamic loads)

up to 0,70 N/mm²

approx. 20%

Peak loads
(rare, short-term loads)

up to 5,0 N/mm²

approx. 60%











Properties

Stärke in mm: 12 mm
Downloads "Sylomer-Polyurethanlager SR 450"
Filter products
Variants

With the help of our variant list you can find your article faster and easier.

Product Nr.
Product
Stärke in mm
85SR045012
 Sylomer-Polyurethanlager SR 450
12 mm
85SR045025
 Sylomer-Polyurethanlager SR 450
25 mm
