Sylomer-Polyurethanlager SR 28

Properties

Stärke in mm: 12 mm

Sylomer-Polyurethanlager SR 28

Product number: 85SR002812
Stärke in mm
m²

Description

Sylomer sound bearing bearing type SR 28

Area of application Pressure load

Deformation

Form factor dependent, the specified values apply to form factor q = 3

Static area of application
(static loads)

up to 0,028 N/mm²

approx. 7 %

Dynamic area of application
(static and dynamic loads)

up to 0,037 N/mm²

approx. 20 %

Peak loads
(rare, short-term loads)

up to 1,0 N/mm²

approx. 75 %

Properties

Stärke in mm: 12 mm
Downloads "Sylomer-Polyurethanlager SR 28"
Filter products
Variants

With the help of our variant list you can find your article faster and easier.

Product Nr.
Product
Stärke in mm
85SR002812
 Sylomer-Polyurethanlager SR 28
12 mm
85SR002825
 Sylomer-Polyurethanlager SR 28
25 mm
