Sichtbetonkegel für Vorlaufkonus

The pressure cones are attached to the spacer tube. After concreting, the pressure cones are removed from the concrete and can be reused.

Robust mash connector made of steel of 5 mm diameter including two sputtered plastic clamps. Keeps the distance between the mashes as well as the distance between the meshes and the formwork. Other concrete cover on request!

Application: For concreting storey ceilings or concrete slabs as spacers for the lower reinforcement. Furthermore, the Speedies surface spacers can also be used very well in the precast concrete plant thanks to the pointed feet. With this design, the pointed feet achieve an optimal concrete flow and thereby reduce visibility in the concrete surface. Your advantage: Material polypropylene-PP Pressure-resistant / very high stability Ergonomic Transport-optimized (Euro pallet) Consumption approx. 1-1.5 pieces / m² patent pending MPA approved

One-piece formwork spacer tube with two sealing plugs, ensuring the specified wall thickness reliably. Spacer tube / cone system tested for watertightness up to 5 bar Fire resistance tested in accordance with EN 1363-1 Complies with the requirements of the W1 guideline

Liquid Formwork Release Agent Cire E-31 – for Architectural Concrete (WGK 3) Cire E-31 is a formwork release agent for the production of high-quality architectural concrete in precast concrete manufacturing. It is suitable for concrete made with white or grey cement, as well as coloured concrete, and is specifically designed to achieve premium exposed concrete finishes. The precast elements can subsequently be left untreated or subjected to further surface treatments such as sandblasting, polishing, grinding, or bush hammering. After drying, Cire E-31 forms a thin wax film on the formwork surface, enabling easy demoulding while producing a smooth, pore-free concrete surface with a uniform and attractive colour. Excellent results are also achieved on timber formwork and board formwork.

High-quality, permanently elastic and varied Adhesive- and Sealing compound - permanently elastic - weatherproof - High tractive force -  chlorine-resistant Package: 290 ml, 12 cartridge/carton (= 6,5 kg)

Mit dem Stopper können Mauerstärken aus Faserzement und Kunststoff innen druckdicht verschlossen werden. Beständigkeit: Wasser, UV, Ozon, verdünnte Säuren + Laugen, Gülle + Jauche, Gärungsmaische, Öle + Bitumen, Radon + Methangas, Temperaturbereich - 35 bis + 70 °C Material TPE Druckprüfung nach beidseitigem Verschluss der Faserbetonrohre: Wasserdicht bis 3 bar, Druckprüfung MFPA Leipzig Erweiterte Druckprüfung von 21,5 bis 23,0 mm Prüfzeugnis für den Stopfen zur Abdichtung in Rohrinnenseite. Bitte Einbauanleitung für Stopper anfordern und beachten.Brandprüfung: Feuerwiderstandsklasse E1 120 nach DIN EN 13501-2 mit Faserbetonmauerstärken Klassifikation DIN EN 13501-1 E = normalentflammbar DIN EN 4102-1 B2 = normalentflammbar

Application: For concreting storey ceilings or concrete slabs as spacers for the lower reinforcement. Furthermore, the Speedies surface spacers can also be used very well in the precast concrete plant thanks to the pointed feet. With this design, the pointed feet achieve an optimal concrete flow and thereby reduce visibility in the concrete surface. Your advantage: Material polypropylene-PP Pressure-resistant / very high stability Ergonomic Transport-optimized (Euro pallet) Consumption approx. 1-1.5 pieces / m² patent pending MPA approved

Plastic plugs (colour gray) to close the spredaer after form removal.

Triangular rod spacer made of fibre reinforced concrete.Manufactoring length 100 cm. Also available in different lenghts (e.g. 18, 25 and 33).
