Masonry tie channels Type HMS 25/15-D galv.
Product number:
69M
Available, delivery time: 1-3 days
Price on request
Skip product gallery
Customers also viewed
Speedies Bar Spacer 20 mm
Application:
For concreting floors or concrete slabs as spacers of the lower preservation. Furthermore, the Speedies surface spacers can also be used very well in the concrete precast plant due to the pointed feet.
Your advantage:
Material polypropylene PP
Pressure resistant / Very high stability
Ergonomic
Transport optimized (europallet)
Consumption approx. 1-1,5 pcs./m²
Product is patent pending
MPA-tested
Log in to see more information
Installationsbloc "Prottelith"
Product properties:
non-flammable
passable
insensitive to moisture
frost-resistent
easy perforation of openings
Bulk density: 300 kg m³, +- 5%
Compressive strength: 240 kPa (10% compression)
Baustoffklasse: A2, s1, dO(ÖNORM EN 13501-1)
Log in to see more information
Formwork stripes
The formwork stripes is used to create recesses in base plates and ceiling. The formwork stripes (length: 10m) are perforated in transverse direction each 5 cm. It is possible to creates recesses in different dimensions. As example: 25 / 25 , 20 / 20 or 15 / 15.
The profiling allows optimum connection in concrete.
Available in all heights from 14 to 36 cm.
Installation instruction:
1. Cut the needed length with a cutter from the roll.
2. Fold the formwork stripes in the required size.
3. Connect the overlapped endings with binding wire.
4. Nail the recess quiver sideward through the punch opening.
Log in to see more information
VIBA-Flex Joint sheet 150 mm with mounting-base
Available in one side and both side coated design
Without fixing clip.
Log in to see more information
Randabschaler
Easy device for shuttering of ceiling etc.Mounting on the walls with any turnbuckle or threaded rod.Height adjustable through longitudinal slot.
Time saving
Easy handling
No Wood surplus
Contact adhesive CEM 805 for swelling waterstop and joint sealing strip
CEM805 is a one-component, neutral-odor sealing and bonding compound based on MS hybrid polymer technology. It is solvent-free, silicone-free and isocyanate-free, cures neutrally, is paint-compatible, weather-resistant and offers good chemical resistance.
Applications:Contact adhesive CEM805 is used as a system sealant and installation adhesive for hydrophilic waterstops, joint sealing sheets and concrete plugs.
Typical applications include:
Sealing and bonding in concrete construction for interior and exterior use
Tested for watertightness up to 5.0 bar hydrostatic water pressure (= 50 m water column) in the DualProof System (PVC-P), at product transitions and on concrete surfaces
Crack-bridging up to 2.50 mm down to -35°C (crack-bridging class A5)
Crack-bridging sealant up to 50 m water column
Suitable for use on plaster, gypsum, ceramic, glass, wood, metal and various plastic substrates, as well as galvanized steel and aluminum
Well suited for bonding construction foils and membranes
Suitable for sealing and bonding applications requiring silicone-free systems on site
Butt joint bonding of SilverSeal using CEM805 has been tested and proven watertight up to 2.5 bar (= 25 m water column) Hydrophilic joint tapes (Art. No. 61L) and swelling rubber profiles can be installed in a backflow-proof manner with CEM805 in accordance with German general building authority approval (abP) Also suitable for use with fresh concrete bonded waterproofing systems and joint sealing metal sheets.
Note: Do not apply on substrates such as bitumen, tar or coatings that may cause incompatibilities and plasticizer migration. Standards and certification CEM805 contact adhesive is tested as a sealant in accordance with EN 15651-1 and certified as EC1Plus according to EMICODE.
Product features and advantages:
Ready-to-use MS polymer installation adhesive and sealant, free of silicone, isocyanates and solvents, with a broad adhesion spectrum
Elastic
Non-corrosive
Neutral odor
Weathering and aging resistant
Good UV resistance
Virtually no shrinkage
No bubble formation
Paint-compatible
Log in to see more information
VIBA mandrel sleeve
Bearing made of plastic to absorb moving forces of VIBA shear force dowel.
The quill zone allows a longitudinal movement up to 20 mm.
In the colours:
yellow
gray
green
blue
black
available.
Log in to see more information
Stone cutting machine STEINADLER mod. SR 1000 H
The machine SR 1000 is a robust stone cutting machine for wet cutting. Provided with a diamond dividing disc it is used for cutting bricks, Ytong, concrete, lime sand brick, clinker and similar material. Robust, powerful and longliving due to its very stable construction.
Technical data:
engine: 7,5 kW 400 V 50 HZ<?xml:namespace prefix = "o" />
water pump: TB 16 0.07 kW 400 V 50 HZ
dividing disc: Ø 900 or 1000 mm Bo 60 mm
cut depth: max. 365/420 mm
cut height: 650 mm
feed: automatic with handrail
Dimension:
overall length 1150 mm
overall width 860 mm
overall height 2000 mm
weight 415 kg
Dreikant-Profilstäbe 20 mm konkav
Rod spacer made of fibre reinforced concrete.Manufactoring length 100 cm. Also available in different lenghts (e.g. 18, 25 and 33).
Log in to see more information
SBA basket
These spacer-baskets are situated between the upper and the lower reinforcment panels.
They don't sit on the formwork (no plastic feet), therefore a proper exposed concrete can be arised.Packing units: big band at 800, 600, 400, 200 pieces, small band at 10 pieces.
Log in to see more information
