Switch/Plug combination with cable
Product number:
56CE0111
Skip product gallery
Customers also viewed
Construction saw AVOLA tyoe IC 450-10
More Safety with new norm EN 1870-1
Saw incl. 1 HM saw blade (nailed down)
Standard equipment:
Safety hood – table extansion
adjustable angle cutting device
undertable guideway, securely protected
Parallel stop with measuring scale
high quality TCT sawblade, noise reduced
machine frame completely galvanized, torsion - resistant
powerful motors with extensive reserves of safety, with magnetic brake
4 loading – unloading devices
Special equipment:
Driving device
Table extansion
Angle cutting device
Roller trestle
Technical data:
Motor power output P1/P2**
KW
4,2/3,2
Three – phase current
Volt
400
AC current
Volt
–
Equipment plug
CEE 516
Fuses, time lag
Amp.
16
Speed
U/min
2760
Sawblade dia. / bor hole
mm
450/30
Cuttung height
mm
153
Table size L x W
mm
1110 x 750
Table height
mm
850
Weight
kg
121
Baukreissäge AVOLA Typ ZBV 500-S
Die ZBV 500-S ist eine höhen- und schrägverstellbare Baustellen-Tischkreissäge mit 500 mm großem Sägeblatt. Mit der ZBV 500-S werden auch Schrägschnitte mit hoher Schnitthöhe auf der Baustelle möglich.
Vor allem das immer mehr verwendete Dämmmaterial kann so optimal in Verbindung mit dem Spezial-Kreissägeblatt bearbeitet werden.
Sonderzubehör: Fahrvorrichtung, Tischverbreiterung, Absaugvorrichtung, Schmiegenlehre zum Anfassen und zur Dreikantprofilherstellung
Construction saw AVOLA BK-450-10
More Safety through EN 1870-1
Saw incl. 1 HM saw blade (nailed down)
Standard equipment:
Safety hood – table extansion
adjustable angle cutting device
undertable guideway, securely protected
Parallel stop with measuring scale
high quality TCT sawblade
machine frame completely galvanized, torsion - resistant
powerful motors with extensive reserves of safety, with magnetic brake
4 loading – unloading devices
Technical Data:
Motor power output P2**
KW
3
Three – phase current
Volt
400
Frequency
Hz
50
Sawblade dia. / bor hole
mm
450/30
Cuttung height
mm
135
Table size L x W
mm
1079 x 750
Table height
mm
850
Weight
kg
113
VIBA - Rebar connection (Double row) type M
Metal box with rough surface.The surface polishing ensures a good connection with concrete and supports the transfer of shear forces.
Rebendable structural steel BST550 with Austrian certificate. (BST 500 on request)
Technical data:
Standard - Elementlength 125 cm.Box heigth h1 = 3 cm;
Other types on request.
By Special types just fill the attached datasheet and send it to us per mail or fax.
Log in to see more information
VIBA-joint sheet roll ACTIVE - 160 mm unilaterally coated with Bentonit
VIBA thick tin Active is a galvanised, unilaterally full-flatly with active Bentonitcoated sealing metal with source effect. In both forking out a 7,5 cm wide high sticking push connection is raised.
incl. 20 connection hangers, 4 push clips + 1,5 m of push connection (self-adhesive)
Log in to see more information
Three-layer plate Standard, thick: 27 mm
Three layer plywood
weather-resistant glued
Surface with melamine-resin (yellow). Other colours on request.
Special formats on request
Additional millings possible!
All standard cuts are possible!
Diem- concrete mixer tilting drum type Allround D 120C
Ahead of its time with the latest compact generation. Professionals use this concrete mixer
Convenient operationThe most important operating elements such as toggle levers and switches are arranged in a user-friendly manner.
Optimal size of the flanged drum openingExcellent accessibility and practical drainage of the concrete.
Light and power connection innovatively combined in one machinePromises versatility on every construction site - 230V and 400V!
Tried and tested chassisThe mobility on construction site terrain is guaranteed.
The specially designed concrete mixer guarantees excellent mixing results. The tilting mixers drum type of the compact generation are extremely robust and maintenance-free, perfectly suited for daily construction site operations.
Technical specifications:
Motor
230/400V 0,75 KW
Transmission
27 ¹ / min
Capacity
180 l
Mixing quantity
120 l
Total heigth
1535 mm
Total width
943 mm
Total length
1350 mm
Drum diameter
643 mm
Drum heigth
631 mm
Tilting gear
-
Weigth
151 kg
Varnishing
RAL 1013
Set of tiers
Solid rubber
SBA basket
These spacer-baskets are situated between the upper and the lower reinforcment panels.
They don't sit on the formwork (no plastic feet), therefore a proper exposed concrete can be arised.Packing units: big band at 800, 600, 400, 200 pieces, small band at 10 pieces.
Log in to see more information
Distanzstreifen AB 6
The distance stripes are situated between the upper and lower reinforcement panel as well as between the external and internal reinforcement wall.
They don t sit on the formwork (no plastic feet) therefore, a proper exposed concrete can be arised.
Packing units: big band at 1.000 pcs., band at 200 pcs., small band at 25 pcs.
